Connector A
|
MPO
|
Connector B
|
MPO
|
|
Patch cord type
|
Trunk/breakout patch cord
|
Fiber number
|
2-72 cores
|
|
MPO IL
|
Standard loss/low loss
|
Polishing
|
SM:APC/MM:PC
|
|
Connector housing color
|
Yellow/Green/Beige/Aqua/Violet/Magenta/Lime green
|
Connector boot type
|
Round/ribbon/bare fiber
|
|
Connctor type
|
Female/Male
|
RL
|
≥20dB(MM);≥60dB（SM）
|
|
IL(Typical )
|
0.1/0.2dB
|
IL(Max. value)
|
0.35/0.6dB
|
|
Transmission rate
|
40G/100G
|
Tolerance
|
﹢6cm
|
|
Cable outer diameter
|
3.0/3.5/4.5/5.0mm
|
Cable color
|
Yellow/Aqua/Violet/Magenta/Lime green
|
|
Cable material
|
LSZH/PVC
|
Flame retardant grade
|
OFN/OFNR/OFNP
|
|
Fiber brand
|
Corning/YPFC
|
Fiber type
|
G657A1/OM3/OM4/OM5
|
|
Working wavelength
|
1310/1550(SM); 850/1300(MM)
|
Fiber loss
|
0.35db@1310nm/0.2dB@1550nm 2.4dB@850nm/0.6dB@1300nm
|
|
Min.bending radius(short term)
|
10D
|
Min.bending radius(long term)
|
20D
|
|
Polarity
|
TYPE A/B/C/others
|
Durability
|
≥500 times
|
|
Operating temperature
|
-10 to 70℃ (14 to 158℉)
|
Storage temperature
|
-40 to 85℃ (-40 to 185℉)
|
